Rotary Sand Screen Plant

Sand screen plant is a facility used in the mining and construction industries to process sand and other granular materials. The plant typically includes a series of screens that are used to sort and separate the sand based on particle size.

The process begins with the raw sand being fed into a hopper, which then transports it to a series of screens. The screens are typically made of wire mesh or perforated metal, and they are arranged in a
series of decreasing sizes. As the sand passes through each screen, smaller and smaller particles are removed, until the desired particle size is achieved.

The separated sand is then transported to storage or further processing, while the larger particles are either reprocessed or discarded. Sand screen plants are commonly used in the production of construction materials, such as concrete and asphalt.

Model	VESSM-10(MOBILE)	VESSM-30(MOBILE)	VESSM-100
Capacity	10 TPH	30 TPH	100 TPH

Overview
Features
Benefits
Gallery

VATSAL Rotary sand screening plant produced by our company is composed of a drum, frame, funnel, reducer, motor, and other parts. After the broken stone enters the drum, the material is sieved by the centrifugal force and jigging of the drum. Sieve out one by one through different screens. After the stones of different specifications are screened out, they are dropped into the belt conveyor through the funnel and sent to the finished product yard. On the one hand, the stone with large particle size flows forward along the slope of the drum and is gradually screened out through the screens of different meshes. The small stones are sieved out and fall into their respective hoppers, and then they are transported by hand or by gravity to the finished product pile.

Wide application, can be customized

Widely used in the classification of materials in mining, building materials, transportation, and energy.

VATSAL can customize rotary drum screens with various specifications and various vibration modes according to the actual situation of different users.

Long service life, less maintenance

Sand rotary screening plant is composed of several circular meshes, the total screening area is much larger than the screening area of other screen types, coupled with high screening efficiency, short equipment running time, so long service life, and wearing parts Less maintenance.

Simple and diverse feeding methods

The feed inlet of the drum screen can be designed according to the actual site. Whether it is a belt, a hopper, or other feeding methods, no special measures are required to smoothly feed.

If you are looking for a reliable machine that is strongly built for long use and power saving, VATSAL is the answer.
